We specialize in water pump controller and accessories production.
Product Details
Main technical data
Start type: DOL(Direct on line)
Qty of controlled pump: Single pump
Protection method: Real motor output power (watts) by power factor
Rated input voltage: AC220V/AC230V Single phase 50HZ/ 60HZ (For customization, please contact the manufacturer.)
Capacitor: Reserved space for installing one capacitor
Rated output power: 0.37kw-2.2kw (0.5hp-3hp)
|
Max Motor Output at 220V 1Ph |
Full Load Max(A) |
Starting Current Max(A) |
|
|
HP |
KW |
||
|
0.5 |
0.37 |
15A |
30A |
|
0.75 |
0.55 |
||
|
1.0 |
0.75 |
||
|
1.5 |
1.1 |
||
|
2.0 |
1.5 |
||
|
3.0 |
2.2 |
||
If starting current over 30A, please contact the manufacturer.
Protection function
- Over load protection
- Pump stalled protection
- Dry run protection with sensor free
- Under voltage protection
- Over voltage protection
- Repeat start protection
- Over temperature protection
Application & Control characteristic
- Control and protect universal pump
- Adopting liquid probe ,float switch or pressure switch or level/pressure transmitter to control pump start and stop
- Applied for water supply by liquid level control through float switch or liquid probe
- Applied for booster by pressure control through pressure switch and pressure tank
- Applied for drainage by liquid level control through float switch or liquid probe
- Applied for drainage by level transmitter
- Applied for booster by pressure transmitter
- Applied for sewage pump with piggy-back float switch
Other features
- WIFI module(Optional)
- Pump last five faults record displaying
- Pump accumulative running time displaying
- LCD screen displaying pump running status
- Memory function when power off & recovery
- Present RS485 port
- Pump shaft anti-rust
- Pump start time delay(Time settable)
- Pump stop time delay(Time settable)
- Remote control panel(Optional)
- LCD screen locked function under auto state(Settable)
- Overflow alarm for drainage application
- Signal transmission distance up to 200m(ON/OFF signal)
- Signal transmission distance up to 20m(Analog signal)
Main installation data
- Working temperature: -25℃-- +55℃
- Working humidity: 20%--90%RH, no drips concreted
- Degree of protection: IP65
- Mounting type: Wall mounting
- Unit dimension (L x W x H): 250×197×114mm
SET/CTN Packing Size
6 sets/ctn 56*35*53cm
Connectable sensors
Liquid probe (standard accessory) / Float switch / Pressure switch / 0.5-4.5V Level transmitter / 0.5-4.5VPressure Transmitter
Typical Application Example
